Twitter Bot

Introduction

This package creates Twitter Bot for demonstrating integration between Cerb and Twitter’s API.

Configure the Twitter service

If you haven’t already, follow these instructions to configure the Twitter service and add your first connected account.

Import the package

Navigate to Setup » Configure » Import Package.

Paste the following package into the large text box:



{
  "package": {
    "name": "Twitter",
    "cerb_version": "9.1.0",
    "revision": 1,
    "requires": {
      "cerb_version": "9.1.0"
    },
    "configure": {
      "prompts": [
        {
          "type": "chooser",
          "label": "Twitter account:",
          "key": "twitter_account_id",
          "params": {
            "context": "cerberusweb.contexts.connected_account",
            "single": true,
            "query": "name:twitter"
          }
        }
      ]
    },
    "placeholders": []
  },
  "bots": [
    {
      "uid": "bot_2",
      "name": "Twitter",
      "owner": {
        "context": "cerberusweb.contexts.app",
        "id": 0
      },
      "is_disabled": false,
      "params": {
        "config": null,
        "events": {
          "mode": "all",
          "items": []
        },
        "actions": {
          "mode": "all",
          "items": []
        }
      },
      "behaviors": [
        {
          "uid": "behavior_20",
          "title": "API: GET search/tweets",
          "is_disabled": false,
          "is_private": true,
          "priority": 50,
          "event": {
            "key": "event.macro.bot",
            "label": "Custom behavior on bot"
          },
          "variables": {
            "var_query": {
              "key": "var_query",
              "label": "query",
              "type": "S",
              "is_private": "0",
              "params": {
                "widget": "single"
              }
            }
          },
          "nodes": [
            {
              "type": "action",
              "title": "Make HTTP Request",
              "status": "live",
              "params": {
                "actions": [
                  {
                    "action": "core.va.action.http_request",
                    "http_verb": "get",
                    "http_url": "https://api.twitter.com/1.1/search/tweets.json?q={{var_query|url_encode}}",
                    "http_headers": "User-Agent: Cerb",
                    "http_body": "",
                    "auth": "connected_account",
                    "auth_connected_account_id": "{{{twitter_account_id}}}",
                    "options": {
                      "raw_response_body": "1"
                    },
                    "run_in_simulator": "1",
                    "response_placeholder": "_http_response"
                  },
                  {
                    "action": "_set_custom_var",
                    "value": "{{_http_response.body|json_pretty}}",
                    "format": "json",
                    "is_simulator_only": "0",
                    "var": "response_json"
                  }
                ]
              }
            }
          ]
        },
        {
          "uid": "behavior_18",
          "title": "API: GET statuses/mentions_timeline",
          "is_disabled": false,
          "is_private": true,
          "priority": 50,
          "event": {
            "key": "event.macro.bot",
            "label": "Custom behavior on bot"
          },
          "nodes": [
            {
              "type": "action",
              "title": "Make API call",
              "status": "live",
              "params": {
                "actions": [
                  {
                    "action": "core.va.action.http_request",
                    "http_verb": "get",
                    "http_url": "https://api.twitter.com/1.1/statuses/mentions_timeline.json",
                    "http_headers": "User-Agent: Cerb",
                    "http_body": "",
                    "auth": "connected_account",
                    "auth_connected_account_id": "{{{twitter_account_id}}}",
                    "options": {
                      "raw_response_body": "1"
                    },
                    "run_in_simulator": "1",
                    "response_placeholder": "_http_response"
                  },
                  {
                    "action": "_set_custom_var",
                    "value": "{{_http_response.body|json_pretty}}",
                    "format": "json",
                    "is_simulator_only": "0",
                    "var": "response_json"
                  }
                ]
              }
            }
          ]
        },
        {
          "uid": "behavior_21",
          "title": "API: GET users/show",
          "is_disabled": false,
          "is_private": true,
          "priority": 50,
          "event": {
            "key": "event.macro.bot",
            "label": "Custom behavior on bot"
          },
          "variables": {
            "var_screen_name": {
              "key": "var_screen_name",
              "label": "screen_name",
              "type": "S",
              "is_private": "0",
              "params": {
                "widget": "single"
              }
            }
          },
          "nodes": [
            {
              "type": "action",
              "title": "Make API Call",
              "status": "live",
              "params": {
                "actions": [
                  {
                    "action": "core.va.action.http_request",
                    "http_verb": "get",
                    "http_url": "https://api.twitter.com/1.1/users/show.json?screen_name={{var_screen_name}}",
                    "http_headers": "User-Agent: Cerb",
                    "http_body": "",
                    "auth": "connected_account",
                    "auth_connected_account_id": "{{{twitter_account_id}}}",
                    "options": {
                      "raw_response_body": "1"
                    },
                    "run_in_simulator": "1",
                    "response_placeholder": "_http_response"
                  },
                  {
                    "action": "_set_custom_var",
                    "value": "{{_http_response.body|json_pretty}}",
                    "format": "json",
                    "is_simulator_only": "0",
                    "var": "response_json"
                  }
                ]
              }
            }
          ]
        },
        {
          "uid": "behavior_19",
          "title": "API: POST statuses/update",
          "is_disabled": false,
          "is_private": true,
          "priority": 50,
          "event": {
            "key": "event.macro.bot",
            "label": "Custom behavior on bot"
          },
          "variables": {
            "var_status": {
              "key": "var_status",
              "label": "status",
              "type": "S",
              "is_private": "0",
              "params": {
                "widget": "multiple"
              }
            }
          },
          "nodes": [
            {
              "type": "action",
              "title": "Make API Call",
              "status": "live",
              "params": {
                "actions": [
                  {
                    "action": "core.va.action.http_request",
                    "http_verb": "post",
                    "http_url": "https://api.twitter.com/1.1/statuses/update.json",
                    "http_headers": "Content-Type: application/x-www-form-urlencoded\r\nUser-Agent: Cerb",
                    "http_body": "status={{var_status|url_encode}}",
                    "auth": "connected_account",
                    "auth_connected_account_id": "{{{twitter_account_id}}}",
                    "options": {
                      "raw_response_body": "1"
                    },
                    "run_in_simulator": "1",
                    "response_placeholder": "_http_response"
                  },
                  {
                    "action": "_set_custom_var",
                    "value": "{{_http_response.body|json_pretty}}",
                    "format": "json",
                    "is_simulator_only": "0",
                    "var": "response_json"
                  }
                ]
              }
            }
          ]
        },
        {
          "uid": "behavior_22",
          "title": "Create Tweet",
          "is_disabled": false,
          "is_private": true,
          "priority": 50,
          "event": {
            "key": "event.message.chat.worker",
            "label": "Conversation with worker"
          },
          "nodes": [
            {
              "type": "action",
              "title": "Prompt for tweet?",
              "status": "live",
              "params": {
                "actions": [
                  {
                    "action": "send_message",
                    "message": "What would you like to Tweet?:",
                    "format": "",
                    "delay_ms": "1000"
                  },
                  {
                    "action": "prompt_text",
                    "placeholder": "(e.g.  This is a tweet posted from #cerb via a chat bot)"
                  },
                  {
                    "action": "_set_custom_var",
                    "value": "{{message}}",
                    "format": "",
                    "is_simulator_only": "0",
                    "var": "prompt_status"
                  }
                ]
              }
            },
            {
              "type": "action",
              "title": "Save status and confirm",
              "status": "live",
              "params": {
                "actions": [
                  {
                    "action": "_set_custom_var",
                    "value": "{{message}}",
                    "format": "",
                    "is_simulator_only": "0",
                    "var": "prompt_status"
                  }
                ]
              }
            },
            {
              "type": "action",
              "title": "Create the new Tweet",
              "status": "live",
              "params": {
                "actions": [
                  {
                    "action": "_run_behavior",
                    "on": "_trigger_va_id",
                    "behavior_id": "{{{behavior_19}}}",
                    "var_status": "{{prompt_status}}",
                    "run_in_simulator": "0",
                    "var": "_behavior"
                  },
                  {
                    "action": "_set_custom_var",
                    "value": "{{_behavior.response_json|json_encode|json_pretty}}",
                    "format": "json",
                    "is_simulator_only": "0",
                    "var": "response_json"
                  },
                  {
                    "action": "send_message",
                    "message": "I created Tweet #{{response_json.id_str}} for you.",
                    "format": "",
                    "delay_ms": "1000"
                  }
                ]
              }
            }
          ]
        },
        {
          "uid": "behavior_15",
          "title": "Get Interactions",
          "is_disabled": false,
          "is_private": false,
          "priority": 50,
          "event": {
            "key": "event.interactions.get.worker",
            "label": "Conversation get interactions for worker",
            "params": {
              "listen_points": "global"
            }
          },
          "nodes": [
            {
              "type": "switch",
              "title": "Point:",
              "status": "live",
              "nodes": [
                {
                  "type": "outcome",
                  "title": "global",
                  "status": "live",
                  "params": {
                    "groups": [
                      {
                        "any": 0,
                        "conditions": [
                          {
                            "condition": "point",
                            "oper": "is",
                            "value": "global"
                          }
                        ]
                      }
                    ]
                  },
                  "nodes": [
                    {
                      "type": "action",
                      "title": "Interactions",
                      "status": "live",
                      "params": {
                        "actions": [
                          {
                            "action": "return_interaction",
                            "behavior_id": "23",
                            "name": "Post a tweet",
                            "interaction": "twitter.tweet.post",
                            "interaction_params_json": "{}"
                          }
                        ]
                      }
                    }
                  ]
                }
              ]
            }
          ]
        },
        {
          "uid": "behavior_23",
          "title": "Handle Interactions",
          "is_disabled": false,
          "is_private": false,
          "priority": 50,
          "event": {
            "key": "event.interaction.chat.worker",
            "label": "Conversation handle interaction with worker"
          },
          "nodes": [
            {
              "type": "switch",
              "title": "Interaction:",
              "status": "live",
              "nodes": [
                {
                  "type": "outcome",
                  "title": "twitter.tweet.post",
                  "status": "live",
                  "params": {
                    "groups": [
                      {
                        "any": 0,
                        "conditions": [
                          {
                            "condition": "interaction",
                            "oper": "is",
                            "value": "twitter.tweet.post"
                          }
                        ]
                      }
                    ]
                  },
                  "nodes": [
                    {
                      "type": "action",
                      "title": "Run Create Tweet",
                      "status": "live",
                      "params": {
                        "actions": [
                          {
                            "action": "switch_behavior",
                            "return": "0",
                            "behavior_id": "{{{behavior_22}}}",
                            "var": "_behavior"
                          }
                        ]
                      }
                    }
                  ]
                }
              ]
            }
          ]
        }
      ]
    }
  ]
}


Click the Import button.

You’ll be prompted to link the Twitter connected account you created earlier.

Click the Import button again.

You should see the following:

Test the integration behaviors

Click on Twitter Bot and then click Behaviors on its card.

Open the card for the API: GET search/tweets behavior.

Click on the Simulator button at the top of the card.

Type in a search query and click the Simulate button.

You should see a JSON response with the results of your Twitter search.

You can use the simulator on the other behaviors to test them as well.

Next steps

At this point you can modify the behaviors to meet your needs. You can use the responses from Twitter’s API in your behaviors.
