Introduction

This package creates Facebook Page Bot for demonstrating integration between Cerb and Facebook pages using the Graph API.

Configure the Facebook service

If you haven’t already, follow these instructions to configure the Facebook service and add your first connected account.

Import the package

Navigate to Setup » Packages » Import.

Paste the following package into the large text box:



{
  "package": {
    "name": "Facebook Page Bot",
    "cerb_version": "9.1.0",
    "revision": 1,
    "requires": {
      "cerb_version": "9.1.0"
    },
    "configure": {
      "prompts": [
        {
          "type": "chooser",
          "label": "Facebook Page:",
          "key": "facebook_account_id",
          "params": {
            "context": "cerberusweb.contexts.connected_account",
            "single": true,
            "query": "name:facebook"
          }
        }
      ],
      "placeholders": [

      ]
    }
  },
  "bots": [
    {
      "uid": "bot_22",
      "name": "Facebook Page Bot",
      "owner": {
        "context": "cerberusweb.contexts.app",
        "id": 0
      },
      "is_disabled": false,
      "params": {
        "config": {
          "api_version": "v2.9"
        },
        "events": {
          "mode": "all",
          "items": [

          ]
        },
        "actions": {
          "mode": "all",
          "items": [

          ]
        }
      },
      "behaviors": [
        {
          "uid": "behavior_127",
          "title": "Get page info",
          "is_disabled": false,
          "is_private": true,
          "priority": 50,
          "event": {
            "key": "event.macro.bot",
            "label": "Custom behavior on bot"
          },
          "nodes": [
            {
              "type": "action",
              "title": "Facebook API Request",
              "status": "live",
              "params": {
                "actions": [
                  {
                    "action": "core.va.action.http_request",
                    "http_verb": "get",
                    "http_url": "https://graph.facebook.com/{{behavior_bot_config.api_version}}/me?fields=about,fan_count,description,general_info,link,rating_count,overall_star_rating,website",
                    "http_headers": "",
                    "http_body": "",
                    "auth": "connected_account",
                    "auth_connected_account_id": "{{{facebook_account_id}}}",
                    "options": {
                      "raw_response_body": "1"
                    },
                    "run_in_simulator": "1",
                    "response_placeholder": "_http_response"
                  },
                  {
                    "action": "_set_custom_var",
                    "value": "{{_http_response.body|json_pretty}}",
                    "format": "json",
                    "is_simulator_only": "0",
                    "var": "_response"
                  }
                ]
              }
            }
          ]
        },
        {
          "uid": "behavior_128",
          "title": "Get page posts",
          "is_disabled": false,
          "is_private": true,
          "priority": 50,
          "event": {
            "key": "event.macro.bot",
            "label": "Custom behavior on bot"
          },
          "nodes": [
            {
              "type": "action",
              "title": "Facebook API Request",
              "status": "live",
              "params": {
                "actions": [
                  {
                    "action": "core.va.action.http_request",
                    "http_verb": "get",
                    "http_url": "https://graph.facebook.com/{{behavior_bot_config.api_version}}/me/posts",
                    "http_headers": "",
                    "http_body": "",
                    "auth": "connected_account",
                    "auth_connected_account_id": "{{{facebook_account_id}}}",
                    "options": {
                      "raw_response_body": "1"
                    },
                    "run_in_simulator": "1",
                    "response_placeholder": "_http_response"
                  },
                  {
                    "action": "_set_custom_var",
                    "value": "{{_http_response.body|json_pretty}}",
                    "format": "json",
                    "is_simulator_only": "0",
                    "var": "_response"
                  }
                ]
              }
            }
          ]
        },
        {
          "uid": "behavior_129",
          "title": "Post to page",
          "is_disabled": false,
          "is_private": true,
          "priority": 50,
          "event": {
            "key": "event.macro.bot",
            "label": "Custom behavior on bot"
          },
          "variables": {
            "var_post_content": {
              "key": "var_post_content",
              "label": "Post Content",
              "type": "S",
              "is_private": "0",
              "params": {
                "widget": "multiple"
              }
            }
          },
          "nodes": [
            {
              "type": "switch",
              "title": "Do we have post content?",
              "status": "live",
              "nodes": [
                {
                  "type": "outcome",
                  "title": "Yes",
                  "status": "live",
                  "params": {
                    "groups": [
                      {
                        "any": 0,
                        "conditions": [
                          {
                            "condition": "var_post_content",
                            "oper": "!is",
                            "value": ""
                          }
                        ]
                      }
                    ]
                  },
                  "nodes": [
                    {
                      "type": "action",
                      "title": "Facebook API Request",
                      "status": "live",
                      "params": {
                        "actions": [
                          {
                            "action": "core.va.action.http_request",
                            "http_verb": "post",
                            "http_url": "https://graph.facebook.com/{{behavior_bot_config.api_version}}/me/feed",
                            "http_headers": "",
                            "http_body": "{% set data = {\r\n \"message\": \"{{var_post_content}}\"\r\n}%}\r\n{{data|url_encode}}",
                            "auth": "connected_account",
                            "auth_connected_account_id": "{{{facebook_account_id}}}",
                            "options": {
                              "raw_response_body": "1"
                            },
                            "run_in_simulator": "1",
                            "response_placeholder": "_http_response"
                          },
                          {
                            "action": "_set_custom_var",
                            "value": "{{_http_response.body|json_pretty}}",
                            "format": "json",
                            "is_simulator_only": "0",
                            "var": "_response"
                          }
                        ]
                      }
                    }
                  ]
                }
              ]
            }
          ]
        }
      ]
    }
  ]
}

Click the Import button.

You’ll be prompted to link the Facebook Page connected account you created earlier.

Click the Import button again.

You should see the following:

Test the integration behaviors

Click on Facebook Page Bot and then click Behaviors on its card.

Open the card for the Get page info behavior.

Click on the Simulator button at the top of the card.

Click the Simulate button.

You should see a JSON response with fields from your linked Facebook page.

You can use the simulator on the other two behaviors to test them as well.

Next steps

At this point you can modify the behaviors to meet your needs. You can use the responses from Facebook’s Graph API in your behaviors.

Use Facebook’s Graph API Explorer to build your API calls, and then copy the details into an Execute HTTP Request action in your bot behavior.
